eSORBA® ESP - ESP (ES G-DP)
Product code
|
ES GxxxDP |
xxx :thickness |
Thickness
(mm) |
0.1~1.0 |
Thickness Gauge |
Density of foam (g/㎤)
|
1.07 |
ASTM D3574-05 |
| Standard Color |
Black |
|
| Tensile strength (kgf/㎠) |
80 |
ASTM D3574-05 |
| Elongation (%) |
200 |
ASTM D3574-05 |
| Tear strength (kgf/㎝) |
1.57 |
ASTM D3574-05 |
| Dimensional Stability(%)*1) |
MD |
0.35 |
22 hrs at 80℃ |
| TD |
0.24 |
| Outgas*2) (%) |
1.4 |
ASTM E 595-06 |
| Water Absorption*3) (%) |
3.7 |
SAE AMS 3568A
at 35℃, 85% RH |
| Embrittlement(℃) |
-42 |
SUM-10*4) |
Recommended Upper
Temperature (℃) |
70 |
SAE J-2236 |
| Resistivity |
Surface
(Ω/□) |
1X1012 |
ASTM D257-92 |
Volume
(Ω-cm) |
1X1010 |
| UL*5) |
V-2 |
UL94 |
*1) 22hrs at 80℃
*2) 24hrs at 125℃ and below 7X10-3 Pa
*3) Weight difference before and after at 23℃, 95% relative humidity for 28 hrs
*4) SK utis method
*5) The UL certifications are available on www.UL.com site
S = Standard; M = Made to Order
| 0.1 |
500X100 |
ES G010DP (S) |
0.07 |
| 0.2 |
ES G020DP (S) |
0.17 |
| 0.3 |
ES G030DP (S) |
0.27 |
| 0.4 |
500X50 |
ES G040DP (S) |
0.37 |
| 0.5 |
ES G050DP (S) |
0.47 |
| 0.6 |
ES G060DP (M) |
0.57 |
| 0.7 |
ES G070DP (M) |
0.67 |
| 0.8 |
ES G080DP (M) |
0.77 |
| 1.0 |
ES G100DP (M) |
0.87 |
| Packing | 1 roll each , wrapped by PE bag in a carton box |
| Export Packing | Max 240 boxes in a 20ft dry container |
Please contact if other thickness is needed.
