eSORBA® DC/DA - SR-J-DA

Technical Data Sheets			Size
	SR J-DA Data Sheet	English	145 KB

Structure:

Properties		SR J-DA series	Test method
Thickness (mm)	Total	0.2~0.3	Thickness Gauge
	Base PET	0.025
	Adhesive	0.025
Density of foam (g/㎤)		0.50	ASTM D3574-05
Standard Color		Black
Initial adhesion (g/inch)	on PC	800	2Kg roller, 180 peel
	on SUS	986
Permanent adhesion (g/inch)	on PC	1552	2Kg roller, 24hr, 180 peel
	on SUS	1408
Embrittlement		130 ℃ / NC

S = Standard; M = Made to Order

Thickness	Roll Size (mm x m)	SR J-DC
0.2	500X100	S
0.25	500X100	M
0.3	500X100	S
0.4	500X100	X
0.5	500X100	X
0.6	500X100	X
0.7	500X100	X
1.0	500X50	X
1.5	500X50	X
2.0	500X50	X

Packing	1 roll each , wrapped by PE bag in a carton box
Export Packing	Max 240 boxes in a 20ft dry container

Please contact if other thickness is needed.
