eSORBA® DC/DA - SR-J-DA
Structure:
Thickness (mm) |
Total | 0.2~0.3 |
Thickness Gauge |
Base PET | 0.025 |
Adhesive | 0.025 |
Density of foam (g/㎤) |
0.50 | ASTM D3574-05 |
Standard Color |
Black |
Initial adhesion (g/inch) | on PC | 800 | 2Kg roller, 180 peel |
on SUS | 986 |
Permanent adhesion (g/inch) | on PC | 1552 |
2Kg roller, 24hr, 180 peel |
on SUS | 1408 |
Embrittlement | 130 ℃ / NC | |
S = Standard; M = Made to Order
0.2 |
500X100 | S |
0.25 |
500X100 | M |
0.3 | 500X100 | S |
0.4 | 500X100 | X |
0.5 | 500X100 | X |
0.6 | 500X100 | X |
0.7 | 500X100 | X |
1.0 | 500X50 | X |
1.5 | 500X50 | X |
2.0 | 500X50 | X |
Packing | 1 roll each , wrapped by PE bag in a carton box |
Export Packing | Max 240 boxes in a 20ft dry container |
Please contact if other thickness is needed.
